TOXFREE® XTREM EVC H07BZ5-F
Flexible halogen free cable for AC charging stations.
Flat LSZH flexible cable for Electric Vehicle Charging infrastructure.
ACCORDING TO: IEC 60502-1
Flat LSZH flexible cable for EVC infrastructure in parkings.
For residential or corporate electric vehicle charging installations.
EV electric vehicle charging cable
Flat cable system
Simplified Installation and Expansion
Typical applications of
eWALL® EVC POWER BUS
Select...
eWALL® EVC Power Bus are the ideal cable solution for Electric vehicle charging stations.
For public electric vehicle charging station infrastructure, including city hubs, airports, and train stations.
For electric vehicle charging station infrastructure, including office buildings & industrial sites.
EV charging stations
eWALL® EVC Power Bus are the ideal cable solution for Electric vehicle charging stations.
Public EV parking: cities, airports…
For public electric vehicle charging station infrastructure, including city hubs, airports, and train stations.
EV parking: office buildings & industrial sites
For electric vehicle charging station infrastructure, including office buildings & industrial sites.
Resources for engineers
eWALL® EVC POWER BUS Technical datasheet
Download file
eWALL® EVC POWER BUS
Technical specifications
Application
Flat LSZH flexible cable for EVC infrastructure in parkings.
For residential or corporate electric vehicle charging installations.
The flat cable system allows you a hassle-free Installation &
easy expansion, all along the installed length of the cable.
The electrician simply connects the new charging stations to
the existing infrastructure
Construction
Conductor
Insulation
XLPE.
Assembly of cores
The cores are parallel in only one layer, forming a flat cable.
Colours and position are the following: Brown + Blue + Green/Yellow + Black + Grey.
Outer sheath
Polyolefin LSZH.
Grey colour.
Compatibility
Cable compatible with all major flat connection modules.
Standards / Compliance
ACCORDING TO: IEC 60502-1
Standards and approvals
- CE.
- RoHS
Construction Products Regulation
- B2ca-s1a, d1, a1.
Disclaimer
The information displayed on this website is provided for reference purposes only and is not legally binding. Specifications, values, and technical data may be subject to change without notice. To obtain verified and up-to-date technical data for a specific cable, please download Top Cable’s official Technical Specification in PDF format. The PDF document constitutes the sole authoritative source of product data.
Characteristics
Electrical performance
0,6/1kV
Thermal performance
Maximum conductor temperature: 90ºC.
Minimum service temperature: -40ºC (fixed and protected installations).
Maximum short-circuit temperature: 250 °C (maximum 5 s.).
Fire performance
Flame non-propagation according to EN 60332-1 and IEC 60332-1.
Fire non-propagation according to EN 60332-3-24 /IEC 60332-3-24/ EN 50399.
Reaction to fire CPR: B2ca-s1a, d1, a1 according to EN 50575.
LSZH (Low Smoke Zero Halogen) according to EN 60754-1 and IEC 60754-1.
Low corrosive gases emission according to UNE-EN 60754-2 and IEC 60754-2.
Low smoke emission according to UNE-EN 61034 and IEC 61034.: Light transmittance > 80%.
Mechanical performance
Minimum bending radius: 5x smaller dimension.
Impact resistance: AG2 Medium severity.
Environmental performance
Chemical & Oil resistance: Acceptable.
UV resistant according to EN 50618.
Water resistance: AD5 Jets.
Electrical performance
Other
Meter by meter marking.
